110Vdc/220Vdc Rectifier Module

HOT PRODUCTS > MODULAR RECTIFIER SYSTEM > 110Vdc/220Vdc Rectifier Module

110Vdc/220Vdc Rectifier Module

Single Input
Input Voltage Range: 90Vac to 265Vac
Rate Input Range: 110Vac/220Vac
Efficiency: ≥93%@220Vac 100% Load
Rated Capcity:
2500W(176Vac～265Vac)
1200W(90Vac～175Vac)
shared：
BR1102500 BR2202500

The rectifier module output current regulation and communication interruption are as follows:
The output current of the rectifier module can be adjusted according to the current command. The adjustment range of BR1102500 is 1A~20A, the adjustment range of BR2202500 is 1A~10A.
Communication fault more than 1 minute (Rectifier and Control monitor),A .Rectifier
module output Voltage automatic recovery default Voltage (BR1102500 is 117V, BR2202500 is 234V） and limited current
function not working;b.if the rectifier modules are controller by monitor and Power off, then
rectifier system will power on(if the rectifier fault, it can not be turned on again)
